Codecs & Voice
Support f or G.711µ/a, G.722 (wide-band), G.726-32, iLBC, Opus, G.729, in-band and
out-of-band DTMF (In audio, RFC2833, SIP INFO), H.264 BP/MP/HP, video resolution up to 480p, frame rate up to 30 fps, bit rate up
to 2Mbps, 3-way video confere
Protocols & Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV,
NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069,
802.1x, TLS, SRTP
Interfaces
HeadSet
RJ9 headset jack (allowing EHS with Plantronics headsets)
Auxilary Ports
Tiltable mega pixel CMOS camera with privacy shutter, Bluetooth 4.0 + EDR, integrated. 802.11 b/g/n, USB, SD, Mini-HDMI, extension module port
LAN Ports
Dual switched 10/ 100/ 1000 Mbps ports with integrated PoE
Phone Feature Keys
Line Keys
11 function keys for PHONEBOOK, BACKSPACE, HEADSET, MUTE, HOLD, MESSAGE,
TRANSFER, CONFERENCE, SPEAKERPHONE, SEND⁄REDIAL, VOLUME. 3 dedicated
Android keys for HOME, MENU, and BACK
Call Features
Maximum SIP Accounts
6 lines, with up
to 6 SIP accounts,
including FREE
IPVideoTalk account
with video mail
Facilities
Hold, transfer, forward (unconditional/no-answer/busy), call park/pickup, 6-way
audio conference, shared-call-appearance (SCA) / bridged-line-appearance (BLA),
virtual MPK, downloadable phone book (XML, LDAP), call waiting, call history,
Applications
Skype, Google Hangouts, Microsoft Lync, Web browser, Adobe Flash, Facebook,
Twitter, YouTube, news, weather, stock, Internet radio, Pandora, Last.fm, Yahoo
Flickr, Photobucket, alarm clock, Google calendar, mobile phone data import/export
Physical Features
Display Type
capacitive (5 points) touch screen TFT LCD
Graphic Display Size
4.3»(480×272)
Management
Provisioning
Firmware upgrade via TFTP / HTTP / HTTPS or local HTTP upload, mass provisioning
using TR-069 or AES encrypted XML configuration file
FTP Support
TFTP
Environmental
Operating Temperature
0°C to 40°C
Operation Humidity
10% to 90%
Phone Dimensions
196.5mm (W) x 206.2mm (L) x 85.2mm (H)
Weight
0.92kg
Mounting
Base Stand
Power Supply
RPS Input/Output
100-240VAC 50-60Hz; Output 12VDC, 1.5A
(18W)
PoE in
Integrated PoE+ (Power-over-Ethernet) 802.3at, Class 4
Power Consumption
DC Input: 3.025~7.5843
PoE Input: 4.050~
9.7166
